72V 7.5KW PMSM motor and controller and rear axle kit for low speed sedan and tricycles etc
$ 98.48
MOTOR PARAMETERS Model EM801 Rated power(kW) 7.5 Max power(kW) 15 Rated torque(N·m) 24 Max torque(N·m) 92 Rated RPM(rpm) 3000 Max RPM(rpm) 7000 Insulation class H Cooling methods(cooling) Air cooling Protection grade IP67 Direction (facing the shaft extension end) Clockwise ■ Counterclockwise Outline dimensions (mm) Φ274.3×265(±2) Shaft spline Internal spline Weight(kg) 24±2 CONTROLLER Model EC750 Battery rated input voltage (VDC) 72V Input battery voltage range 48v-96v Rated output current (A) 200 Maximum output current (A) 500 Rated capacity (KVA) 17.5 Maximum capacity (KVA) 35 Protection level IP67 Auxiliary power supply voltage (VDC) 72(Bus voltage) Main body size (mm) 227*159*93±2.0 Mass (kg) 3±0.5 The rear axle is made per customer’s request. Discuss detailed loading capacity, ratio, max speed, length of axle etc
